Product Overview
The IoT Pro – Location Tracker Module is a multi-purpose industrial asset tracking device designed to provide precise location visibility and operational status of mobile and remote assets across diverse environments.
A key characteristic of the module is its flexible power architecture, allowing deployment on both unpowered and externally powered assets:
-
For unpowered assets, the device supports high-capacity internal batteries up to 17Ah, enabling multi-year autonomous operation with optimised GNSS and transmission duty cycles.
-
For powered assets, the module can operate from an external DC supply (10–30V) while maintaining an internal rechargeable battery backup, for security purposes.
The module combines multi-constellation GNSS positioning, low-power embedded architecture, and integrated I/O interfaces, enabling it to function as a reliable edge tracking node for asset monitoring systems.
It is engineered for retrofit deployment on existing assets such as containers, vehicles, machinery, and infrastructure equipment without requiring integration into existing control systems.
From a system architecture perspective, the device operates as an independent telemetry node, capturing location, movement behaviour, and auxiliary signals (e.g. ignition, access, sensor states), and transmitting structured data suitable for integration into fleet management, asset tracking, and infrastructure monitoring platforms.
The module is a long-term industrial tracking device designed for predictable behaviour, low maintenance, and stable integration over extended deployment lifecycles.
Typical Installation Points
The IoT Pro Location Tracker Module is typically deployed on mobile, semi-mobile, or remote assets where location visibility and operational awareness are required. These installations often involve harsh environmental exposure, limited accessibility, and long service intervals, requiring robust hardware and multi-year autonomous operation.
Intermodal Logistics Assets
ISO Containers / Well Cars / Drayage Tractors / Reach Stackers
Heavy Machinery
Excavators / Loaders / Cranes & Lifting Equipment
Trailers & Transport Assets
Dry Van Trailers / Refrigerated Trailers / Tanker Trailers
Marine & Floating Assets
Yachts / Fishing Boats / Dredgers / Floating Cranes
Generators & Power Units
Diesel Generators / Rental Generator Sets / Solar Generator Units
Off-Grid Infrastructure
Mobile CCTV Towers / Mobile Pumping Units / Portable Lighting Towers
Measurement & Functional Capabilities
The IoT Pro Location Tracker Module is designed to provide high-accuracy positioning, movement intelligence, and auxiliary asset monitoring, with a focus on long-term reliability and power efficiency.
GNSS Positioning Engine
The module integrates an advanced multi-constellation GNSS receiver, enabling accurate positioning across global deployments.
GNSS Specifications
The use of multi-constellation GNSS ensures reliable positioning even in urban, obstructed, or partially shielded environments, improving availability.
GNSS | Multi-GNSS engine for GPS, GLONASS, BDS, Galileo, and QZSS |
Precision (CEP 50) | 2.0 m |
Key Features | SBAS ranging (WAAS, EGNOS, GAGAN, MSAS) | Integrated LNA improves sensitivity | Embedded multi-tone active interference canceller for anti-jamming |
Receiver Type | 47 Channels GNSS Receiver |
Sensitivity | Cold Start: -147 dBm | Tracking: -166 dBm | Reacquisition: -159 dBm |
Time-To-Frist Fix | Cold start: 15 s | Hot start: 2 s |
Precision (CEP 50) | 2.0 m |
GNSS Specifications
The use of multi-constellation GNSS ensures reliable positioning even in urban, obstructed, or partially shielded environments, improving availability.
GNSS | Multi-GNSS engine for GPS, GLONASS, BDS, Galileo, and QZSS |
Precision (CEP 50) | 2.0 m |
Key Features | SBAS ranging (WAAS, EGNOS, GAGAN, MSAS) | Integrated LNA improves sensitivity | Embedded multi-tone active interference canceller for anti-jamming |
Receiver Type | 47 Channels GNSS Receiver |
Sensitivity | Cold Start: -147 dBm | Tracking: -166 dBm | Reacquisition: -159 dBm |
Time-To-Frist Fix | Cold start: 15 s | Hot start: 2 s |
Precision (CEP 50) | 2.0 m |
GNSS Specifications
The use of multi-constellation GNSS ensures reliable positioning even in urban, obstructed, or partially shielded environments, improving availability.
GNSS | Multi-GNSS engine for GPS, GLONASS, BDS, Galileo, and QZSS |
Precision (CEP 50) | 2.0 m |
Key Features | SBAS ranging (WAAS, EGNOS, GAGAN, MSAS) | Integrated LNA improves sensitivity | Embedded multi-tone active interference canceller for anti-jamming |
Receiver Type | 47 Channels GNSS Receiver |
Sensitivity | Cold Start: -147 dBm | Tracking: -166 dBm | Reacquisition: -159 dBm |
Time-To-Frist Fix | Cold start: 15 s | Hot start: 2 s |
Precision (CEP 50) | 2.0 m |
Movement & Tracking Behaviour
The module supports configurable tracking logic, enabling:
-
Periodic location updates (time-based)
-
Movement-triggered reporting (tilt / motion-based)
-
Event-based transmission (e.g. ignition, access events)
This allows deployments to balance tracking granularity with power consumption, depending on application requirements.
Channel Architecture
The IoT Pro Location Tracker Module maintains the same scalable I/O architecture as other IoT Pro modules, enabling hybrid tracking + sensing deployments.
Standard Configuration
-
GNSS positioning engine (Primary function)
Additional I/O Interfaces
In addition to location tracking, the hardware platform is pre-engineered to support additional sensing and control interfaces for combined or future-use deployments.
Digital Inputs
6 × Digital Inputs Configurable as
Dry Contact Inputs
Pulse Inputs
Temperature Probes (DS18B20)
Suitable for ignition detection, door/access monitoring, equipment state monitoring, event-triggered tracking
Analog Input
1 x 0-30 V Voltage Input
Suitable for battery voltage and analogue fuel level reading
1 × 4–20 mA analog input
Suitable for industrial transmitters such as pressure, level, flow, or gas sensors
Digital Output
2 x Digital Open-Drain Output
500 mA Continuous Current
Up to 1 A Pulse Capability
These outputs may be used for relay driving, signalling, or interfacing with external equipment where local actuation or indication is required, such as immobilizer or alarm functionality.
IoT Pro Hardware Architecture
Power-Intelligent Long-Life Operation
Supports multi-year battery operation using high-capacity lithium batteries (up to 17Ah) with hybrid pulse architecture, as well as external DC supply (10–30V) with automatic fallback to internal rechargeable battery.
Rugged Industrial Enclosure
IP68 / IK10 enclosure using UV-stable glass-reinforced materials, suitable for outdoor, marine, and industrial environments.
Integrator-First Stable Protocol
All IoT Pro devices use a backward-compatible communication protocol, ensuring long-term stability and eliminating the need for firmware-dependent integration updates.
Remote Lifecycle Management
Full support for remote configuration, firmware updates, and device diagnostics without physical intervention.
Technical Documentation
All documentation is written for software integrators, system engineers, and deployment teams and aligns with the IoT Pro platform architecture.
